NS Bikes präsentiert sein erstes E-MTB das E-Fine Neus E-Enduro Mountainbike

NS Bikes präsentiert sein erstes E-MTB das E-Fine

Scroll hier

NS Bikes präsentiert sein erstes E-MTB das E-Fine – E-Fine ist abgeleitet vom beliebten und bekannten NS Bikes Enduro Modell, dem Define, mit einer Geometrie, mit der man jede Menge Uphill- und Abfahrtsspaß haben kann oder einfach den ganzen Tag im Park verbringt. Das E-Fine wird in zwei Versionen erhältlich sein. E-Fine 1 mit Shimano EP8 – 170/160mm Federweg und 630 Wh Akku, sowie das E-Fine 2 mit Shimano E7000 Motor, 160/150mm Federweg und 504 Wh Akku. Die ersten Bikes werden ab Mitte April lieferbar sein!

DSC09000 @piotrjurczak.eu

NS Bikes präsentiert sein erstes E-MTB das E-Fine

The expansive NS Bikes family tree was recently struck by lightning, and a new electrifiedmodel grew from that bolt of energy. We named it E-fine, following the grain of ourDefinemodels with their gravity geo that’s poised to party or race all day long

DSC09042 @piotrjurczak.eu

This full-powered branch didn’t sprout simply because every other bike company now has anelectric arm.Over the years we have tested a lot of ebikes without finding one that truly stoleour team’s heart. It took us a while to figure out what kind of ebikewe wanted. We askourselves what truly makes an e-bike great? If we put the motor aside for a moment, it allcomes down to the geometry and suspension, and these are the main points that we focusedon.With a hydroformed aluminum frame thattidies cables under the downtube just like our otherbikes, this mixed-wheel machine keeps maintenance times to a minimum. At NS weappreciate options as much as you do, and our E-fine1 bikes will come with a 170mm forkand a 160mm rear axle path, poweredby the tried and trusted Shimano EP8 motor and thebrand’s long-lasting 630 Wh battery. On the second step of our electric podium, the E-fine2model offers a 160mm fork followed by 150mm of rear-wheel travel that’s propelled by aShimano E7000 unit and matching 504 Wh battery.  NS Bikes präsentiert sein erstes E-MTB das E-Fine

DSC09472 @piotrjurczak.eu

We know precisely how an NS bike should feel on the trail and have worked hard to maintainthose high expectations with this latest electrified offering. The Efine’s added heft and powerrequire a nuanced suspension tune to give the pilot maximum comfort in the trickiest trailsituations. Both of these long-travel sleds were carefully designed to provide the support and comfort that riders have come to expect from our bikes, leaving the Efine every bit as fun toshred as our purely muscle-powered models.

DSC01618 @piotrjurczak.eu

Countless hours were spent testing and perfecting each angle of the Efine frame, culminatingin a geometry we’re proud to share with our customers. Efine1 frames are cut in three sizesto fit as many riders as possible, with a small stretching its reach to 425mm, 450mm for amedium, and 480mm on the size large bike. The head tube angle leans back to a cool 63.8°for the steepest descents, while the 75.2° effective seat tube angle provides a nice perch toclimb back up for more. Out back, a set of 455mm chainstays balance the frame and providea stable platform for speed.One branch down on the family tree, reach measurements for the slightly shorter travel Efine2are 430, 456, and 484mm respectively. The bike’s head tube is atouch steeper to suit its all-arounder intentions at 64.1°, and the seat tube also leans forward a skosh to 75.6°.

The 27.5”rear tire is flanked by the same 455mm chainstays on either side.Bottom brackets on the Efine1 and 2 drop the rider’s weight just where we want it, with a345mm height on the 160mm frame and 343mm between the BB and the dirt for the 150mmsled. We went with 160mm crank arms on all sizes of the Efine1, and 165mm cranks on theEfine2 to minimize pedal strikes while keeping the pilot’s pounds as low as possible.We made sure to hang all of the electric-ready components off these two builds, preparingthem for long adventures and low maintenance. A RockShox Super Deluxe Coil Select keepsthe rear wheel running smoothly on the Efine1, led by a Zeb Charger R 29 fork under thehandlebar. The bike’s burly stature is slowed by a set of Magura MT7 brakes and 203mmrotors, and that power grips the ground with a pair of Maxxis Assegai tires in their DoubleDown casing and Max Grip tread. Moving forward, each of Efine1 drivetrain bits come fromthe reliable Shimano Deore 12-speed line, selected for maximum durability.

DSC09443 @piotrjurczak.eu

To save a few pennies while maintaining a quality build spec, Efine2 shifts with Shimano’sDeore 11-speed drivetrain and slows down via a set of Deore 4-piston brakes. An X-FusionHC3 coil takes care of rear-end impacts and RockShox 35 Gold RL fork manages the mayhemup front. A size medium Efine1 tips the scale at 22.5 Kg while the Efine2 weighs 24.5 Kg in the samesize. Both models will be availablein Aprilwith retail pricing set at (€7599) for the Efine1 and(€6299) for the Efine2 . NS Bikes präsentiert sein erstes E-MTB das E-Fine

NS Bikes präsentiert sein erstes E-MTB das E-Fine mehr Infos dazu findet Ihr auf der NS Bikes Webseite
